The XL4015 DC DC Voltage Regulator is a converter with very small dimensions that can adjust the input voltage in the range of 8V and 36V to the output voltage in the December of 1.25V and 32V.

With the XL4015 DC DC voltage regulator, you can eliminate the problems caused by voltage height or low in your projects at the development stage. You can adjust the output voltage according to your request with the trimpot on the product. It is quite convenient with its small dimensions. Up to 5 Amps of current can pass through.

Note: If the output voltage is not set, the output voltage will be equal to the input voltage, and if you connect a 30V input, you can set the desired voltage in the December range of 0-30V. However, if you connect 12V to the input, you can set the output in the December 0-12V range.

• Size : 5.2x2.65 x 1.4 cm
• Input voltage : 8V-36V (Do not exceed the maximum Voltage value)
• Output voltage: 1.25V-32V
• Output current: adjustable maximum 5A
• Conversion efficiency : 95% (maximum)
• Switching frequency: 180KHz
• Output ripple : 50mV (max) 20 m bandwidth
• Load Regulation: ±0.5%
• Voltage Regulation: ±2.5%
• Working Temperature : -40°C to +85°C
