Iveco VCM Control Module Programming - Autovei Solutions

The License Iveco VCM by Autovei supports FLASH and EEPROM read/write operations for VCM2 and VCM3 drive control modules in Iveco trucks. With Autovei, both diagnostics and recovery operations can be performed reliably.

VCM2 Operation Modes:

• OBD mode — Flash and EEPROM read/write, no checksum.
• DC mode — Flash and EEPROM read/write, diagnostics, no need to open VCM, no checksum.
• BSL mode — Full Flash and EEPROM read/write, requires opening VCM and soldering adapter, used for recovery.

VCM3 Operation Modes:

• DC mode — Diagnostics only.
• BSL mode — Full Flash and EEPROM read/write, requires opening VCM and soldering adapter, used for recovery.

Autovei Hardware Requirements:

• VEI V6 or VEI V7 device
• OBD2F-4-IVECO 30 pin round adapter (for older models)
• Direct Connect 2U tool with OBD2 power cable
• DC2U-VCM2/VCM3 cable
• DC2-VCM2 ISP5 cable (for BSL mode)
• DC2-VCM3 ISP4 cable (for BSL mode)
