THINKCAR Reader 8 – Full System Bi-Directional Diagnostic Tool

Reader 8 is a full system OBDII diagnostic tool developed by THINKCAR and is compatible with approximately 95% of passenger vehicles on the market. Reader 8 provides access to all control units including engine, transmission, ABS, airbag, AdBlue, DPF, and more.

With its advanced hardware and software infrastructure, Reader 8 performs fault code reading and clearing, live data monitoring, and actuation tests quickly and reliably. For professional workshops, Reader 8 offers a powerful diagnostic solution.

Featuring a next-generation design, Reader 8 is equipped with a 6.2-inch touch screen and a modern user interface, providing ease of use for both workshops and DIY users. Thanks to its compact structure, Reader 8 can be used comfortably in any environment.

Reader 8 Key Features

• Full system diagnostics for all vehicle systems
• Read and clear fault codes
• Live data stream monitoring
• Actuation / Bi-Directional test support
• 15 different service functions with Reader 8

Supported Protocols

Reader 8 supports OBDII and EOBDII protocols including ISO 14230-4 (KWP2000), CAN FD, ISO 15765-4 (CAN), ISO 9141-2, ISO 14229 (UDS), and SAE J1850 (VPW & PWM).

Reader 8 Service Functions

• Air Flow
• ABS
• AdBlue
• Battery Matching
• Clutch Adaptation
• DPF Regeneration
• EGR
• ETS
• Gear Learning
• Gearbox
• Injector Coding
• NOx Sensor
• Oil Reset
• SAS Reset
• TPMS Reset

Language Support

Reader 8 supports a total of 28 languages including Turkish. With its multi-language infrastructure, Reader 8 is suitable for global use.

Reader 8 Technical Specifications

• Processor: MT8167 Cortex-A53 Quad-core 1.8GHz
• Memory: 32GB ROM / 2GB RAM
• Screen: 6.2-inch touch screen
• Battery: 4150mAh / 3.8V
• Cable: 1.2 meter diagnostic cable
• Software: Lifetime free updates
• Warranty: 1 Year

Reader 8 is a reliable solution for diagnostic needs with its powerful hardware, wide vehicle coverage, and stable software structure. For workshops, Reader 8 combines performance and ease of use in one device.
