LM2596 Adjustable Voltage Regulator
$2.03
You can adjust the output voltage according to your request via the trimpot on it. This module, which is very useful with its small dimensions, has the LM2596 regulated integrated on it. The circuit can carry current up to 3A DC. A small deviation margin of 30 MV provides a great advantage over other DC-DC converters. Note: Since the product is a voltage reducer, the output voltage cannot be more than the input voltage. If you connect a 30V input, you can set the desired voltage 0-30V range. However, if you connect 12V to the input, you can set the output range of 0-12V.
-
Secure Payment
-
Fast Delivery
-
Easy Returns
-
Satisfied Customer
You can regulate the input voltages between 4V DC - 35V DC in the range of 1.23V Dc - 30 VDc.
You can adjust the output voltage according to your request via the trimpot on it.
This module, which is very useful with its small dimensions, has the LM2596 regulated integrated on it.
The circuit can carry current up to 3A DC.
A small deviation margin of 30 MV provides a great advantage over other DC-DC converters.
Note: Since the product is a voltage reducer, the output voltage cannot be more than the input voltage. If you connect a 30V input, you can set the desired voltage 0-30V range. However, if you connect 12V to the input, you can set the output range of 0-12V.
LM2596 Voltage Reducer Adjustable Power Module Technical Specifications
Module feature: Non-insulated buck
Correction mode: Asynchronous correction
Size: 43* 20 * 12 mm (Length*Width*Height)
Type: LM2596 Adjustable Power Supply Module
Input Voltage: DC 4V-35V
Output Voltage: DC 1.23V-30V
Output Current: 3A (Maximum)
Conversion Efficiency: 92% (The Highest)
Output Ripple: 30mv (Maximum)
Switching Frequency: 150kHz
Load regulation: 0.5%
Voltage regulation: 2.5%
Working temperature: -40 degress to +85 degress
