TCM read/write Flash/EEPROM over OBD/DC/JTAG.

Supported:

1. Bosch TCM:
FLASH: MPC5566 (3072 KB)
EEPROM: 95640  (8KB)
DC/OBD mode. No JTAG mode

2. Wabco TCM:
FLASH: MPC5644 (4096KB)
EEPROM: 95640  (8KB)
DC/OBD/JTAG mode

3. Festo TCM:
FLASH: TC1799 (3072 KB+64KB)
EEPROM: 95640  (8KB)
DC/OBD mode. No JTAG mode


Hardware requirements:
VEI V6/V7 device
Direct Connect 2U tool with OBD2 power cable
DC2U-TCM cable
DC2U-ISP-JTAG+BDM dongle (for JTAG mode)
DC2U-JTAG8 flex adapter (for JTAG mode)


IMPORTANT: Bosch and FESTO TCM versions do not have JTAG connection. Wrong dump or unexpected abort of operation can damage ECU. Use read/write functions at your own risk!


License is available from software v6.20 (2022-05-23)
