Scania COO7 License – Coordinator ECU (FLASH & EEPROM Read/Write)

With Autovei solutions, it is possible to perform Flash and EEPROM read/write operations on the COO7 Coordinator ECU used in Scania trucks.

Supported MCU:

• MPC5554

Operation Modes:

• OBD: Flash read/write only, EEPROM not possible (only JTAG mode), no checksum.
• DC: Flash read/write only, EEPROM not possible (only JTAG mode), no checksum. Bench connection with cable without opening ECU, diagnostics on bench supported.
• JTAG: Full Flash & EEPROM read/write, COO7 must be opened and adapter soldered, for recovery, no checksum.

Hardware Requirements:

• Autovei VEI V6/V7 device
• Direct Connect 2U tool with OBD2 power cable
• DC2U-COO7 cable
• DC2U-ISP-JTAG+BDM dongle
• DC2U-JTAG8 flex adapter
