THINKCAR PLD 222 – Next Generation Automotive Leak Tester

THINKCAR PLD 222 is a high-performance automotive leak tester equipped with TURBO and EVAP modes. With its one-touch mode switching feature, this device provides a reliable, fast, and professional solution for air and smoke testing in vehicles.

Key Features

• Turbo and EVAP Mode Support – Easy mode switching with a single button
• Built-in Air Pump – No need for external equipment
• High Smoke Output – Large 12L/min smoke flow for fast testing
• Dual Testing Modes – Perform both air and smoke testing in one device

Comprehensive Testing Capabilities

THINKCAR PLD 222 is designed to quickly and accurately detect leaks in piping systems during automotive repairs. It can be used to test the following systems in vehicles and motorcycles:

• Intake System Testing
• Exhaust System Testing
• Cooling System Testing
• Crankcase System Testing
• Vehicle Sealing Test
• Fuel Tank Testing
• Turbo System Testing
• Pipe Connection Testing

Wide Range of Applications

PLD 222 is a universal solution applicable to all types of vehicles. It provides extensive leak detection and sealing control in various systems. Main application areas include:

Dual Mode: Air & Smoke

THINKCAR PLD 222 features two different test modes: Air Mode and Smoke Mode. Both airflow and smoke output can be adjusted, ensuring the most suitable test conditions for different systems.

Why Choose THINKCAR PLD 222?

• Fast and accurate leak detection
• Ideal solution for professional workshops
• User-friendly control panel
• Comprehensive solution with multi-test support in a single device

Model	PLD-222(TURBO+EVAP)	PLD-212(EVAP)	PLD-212(TURBO)
Income	DC12V	DC12V	DC12V
Flow	6A	6A	6A
Pipeline Length	2.5m	2m	2m
Power Supply Cable	1.5m	2m	2m
Main Unit Flow Rate	0-12L/Min	0-12L/Min	0-12L/Min
Air Pump Flow Rate	8-15L/Day	8-15L/Day	8-15L/Day
Fat Volume	30 ml	45 ml	45 ml
Maximum Outlet Pressure	1.2 bar-TURBO Modu 3.5 kpa-EVAP Modu	4KPa	16PSI
Weight	3kg	3kg	3kg
Warranty	1 Year	1 Year	1 Year
